プロダクト細部
起源の場所: 中国
ブランド名: Tankii
証明: ISO9001
モデル番号: Rタイプ熱電対線
ドキュメント: Tankii Alloy Catalog.pdf
支払及び船積みの言葉
最小注文数量: 50m
価格: 50-100USD /M
パッケージの詳細: 場合
受渡し時間: 5〜7日間
支払条件: L/C、D/A、D/P、T/T、ウェスタンユニオン
供給の能力: 5000M/Month
アイテム: |
Rタイプ熱電対線 0.25mm 0.35mm 価格 |
dia: |
0.1～0.5mmm |
表面: |
明るい |
ポジティブ: |
PT90 |
Negtive: |
RH10 |
MOQ: |
1m |
アイテム: |
Rタイプ熱電対線 0.25mm 0.35mm 価格 |
dia: |
0.1～0.5mmm |
表面: |
明るい |
ポジティブ: |
PT90 |
Negtive: |
RH10 |
MOQ: |
1m |
R type thermocouple wire 0.25mm 0.35mm price
Product Description
Tankii Type S Thermocouple (Platinum Rhodium - 10% / Platinum): The Type S is used in very high temperature applications.
It is commonly found in the BioTech and Pharmaceutical industries.
It is sometimes used in lower temperature applications because of its high accuracy and stability.
The type S is often used with a ceramic protection tube.
Platinum rhodium thermocouple(S/B/R TYPE)
Platinum Rhodium Assembling Type Thermocouple is widely used in production places with high temperature. It is mainly used to measure temperature in glass and ceramic industry and industrial salting
Insulation material: PVC, PTFE, FB or as per the customer's requirement.
Application of thermocouple wire
• Heating - Gas burners for ovens
• Cooling - Freezers
• Engine protection - Temperatures and surface temperatures
• High temperature control - Iron casting
Parameter:
| Chemical Composition | |||||
| Conductor Name | Polarity | Code | Nominal Chemical Composition /% | ||
| Pt | Rh | ||||
| Pt90Rh | Positive | SP | 90 | 10 | |
| Pt | Negative | SN,RN | 100 | -- | |
| Pt87Rh | Positive | RP | 87 | 13 | |
| Pt70Rh | Positive | BP | 70 | 30 | |
| Pt94Rh | Negative | BN | 94 | 6 | |
| Working temperature range | |||
| Dia. /mm | Type | Long time working temp./ ºC | Short time working temp. / ºC |
| 0.5 | S | 1300 | 1600 |
| 0.5 | R | 1300 | 1600 |
| 0.5 | B | 1600 | 1700 |
