プロダクト細部
起源の場所: 上海,中国
ブランド名: TANKII
証明: ISO9001
モデル番号: APM
支払及び船積みの言葉
最小注文数量: 10kg
価格: 交渉可能
パッケージの詳細: Woonedの場合
受渡し時間: 7〜20日
支払条件: L/C、T/T、Western Union
供給の能力: 1ヶ月あたりの300トン
モデル: |
TK APM |
材料: |
フェクロール |
マックス 温度を使う: |
1420 |
密度: |
7.1 g/cm3 |
仕様: |
0.1-10.0 mm |
生産能力: |
300トン/月 |
モデル: |
TK APM |
材料: |
フェクロール |
マックス 温度を使う: |
1420 |
密度: |
7.1 g/cm3 |
仕様: |
0.1-10.0 mm |
生産能力: |
300トン/月 |
TKYZ product is a new product developed after TK1 product, which has been widely used in high temperature electric heating alloy materials in recent years. Compared with TK1, its purity is further improved and its oxidation resistance is further optimized. With the special rare earth element combination and unique metallurgical manufacturing process, the material has been recognized by domestic and foreign customers in the field of high temperature and heat resistant fibers. Successful application in ceramic sintering, diffusion furnaces, industrial furnaces with high power density and high temperature.
MAIN CHEMICAL ELEMENTS AND PROPERTIES
| Properties Grade | HNYZ | |||||||||
| Cr | Al | C | Si | |||||||
| 20-23 | 5.8 | ≤0.04 | ≤0.4 | |||||||
| Max Continuous Service Temperature(ºC) | 1425 | |||||||||
| Resisivity 20ºC (μ.Ω.m) | 1.45 | |||||||||
| Density(g/cm3) | 7.1 | |||||||||
| Tensile Strengtht(N/mm²) | 650-800 | |||||||||
| Elongation (%) | >14 | |||||||||
| High Temperature Strength(MPa) at 1000℃ | 20 | |||||||||
| Fast Life at 1350 ℃ | More than 80 hours | |||||||||
| The Emissivity Of The Fully Oxidized State | 0.7 | |||||||||
Average Linear Expansion Coefficient
| Temperature ℃ | Average thermal expansion coefficient×10-6/k |
| 20-250 | 11 |
| 20-500 | 12 |
| 20-750 | 14 |
| 20-1000 | 15 |
| 20-1200 | - |
| 20-1400 | - |
Thermal Conductivity
| 20℃ | 600℃ | 800℃ | 1000℃ | 1200℃ | 1400℃ | |
| Wm-1k-1 | 13 | 20 | 22 | 26 | 27 | 35 |
Resistance temperature correction factor
| Temperature ℃ | 700 | 900 | 1100 | 1200 | 1300 |
| Ct | 1.02 | 1.03 | 1.04 | 1.04 | 1.04 |
